HIKMICRO Lynx 3.0 LH25 Thermal Monocular – 25mm 384×288 12µm <15mK

RRP: $2,099.00

The Lynx 3.0 LH25 delivers outstanding performance with a 384 × 288 thermal detector, 25mm F1.0 lens, and 2.5× base magnification, making it ideal for longer-range observation. Designed for hunters, wildlife observers, and professional outdoor use, it offers a 10.5° field of view and an impressive detection range of up to 1,200 metres, making it well suited to open landscapes and wide terrain.

Advanced imaging technologies including AI-powered Image Pro 3.0, Zoom Pro, and the HIKMICRO Shutterless Imaging System (HSIS) ensure clear, stable thermal images without interruptions from shutter calibration.

Compact and lightweight at only 328.5g, the Lynx LH25 runs on a replaceable 18650 rechargeable battery and features a 1920 × 1080 OLED display for sharp image detail in all conditions.

---

Key Features

• High-sensitivity thermal sensor with NETD < 15mK (@25°C, F1.0)

• 25mm F1.0 lens with detection range up to 1,200m

• 384 × 288 resolution with 12µm pixel pitch

• AI-powered Image Pro 3.0 and Zoom Pro image enhancement

• HIKMICRO Shutterless Imaging System (HSIS) for uninterrupted viewing

• 1920 × 1080 OLED display

• Replaceable 18650 rechargeable battery

• Up to 5 hours runtime (25°C) or 4.5 hours at -20°C

• 64GB internal storage for images and video

• Wi-Fi hotspot (2.4 / 5 GHz) for mobile connectivity

• Compact 328.5g lightweight design

---

Specifications

Thermal Module

• Sensor Type: VOx Uncooled Focal Plane Array

• Resolution: 384 × 288

• Frame Rate: 50 Hz

• Pixel Pitch: 12µm

• Spectral Range: 8–14µm

• NETD: <15mK (@25°C, F1.0)

• Lens: 25mm F1.0

• Focus Mode: Manual Focus Ring

• Detection Range: 1,200m

• Minimum Focus Distance: 3m

• Magnification: 2.5× – 20× (8× digital zoom)

• Field of View: 10.5° × 6.4°

• Field of View @100m: 18.4m × 11.2m

---

Display

• Display Type: 0.49" AMOLED

• Resolution: 1920 × 1080

• Exit Pupil: 6mm

• Eye Relief: 20mm

• Diopter Adjustment: -5D to +3D

Colour Palettes

• Black Hot

• White Hot

• Red Hot

• Fusion

• Red Monochrome

• Green Monochrome

Image Controls

• Brightness Adjustment

• Contrast Adjustment

• Tone Modes: Cold / Warm

• Zoom Pro

• Image Pro 3.0

• HSIS (Shutterless Image System)

• Sync Pro

---

System Features

• Video Recording

• Snapshot Capture

• Audio Recording

• Standby Mode

• 64GB Built-in EMMC Storage

• Picture-in-Picture (PIP)

• Hot Track

• Distance Measurement

• Local Album

• Wi-Fi Hotspot (2.4GHz / 5GHz)

---

Power

• Battery Type: Replaceable & Rechargeable 18650 Li-ion

• Battery Life:

  • Up to 5 hours (hotspot on @25°C)

  • Up to 4.5 hours (hotspot on @-20°C)

• Charging: USB-C (5V DC, 2A)

• Supports external power supply

---

General

• Ingress Protection: IP67

• Dimensions: 158.4 × 53.6 × 49.5 mm

• Weight: 328.5g (with battery)

• Operating Temperature: -30°C to 45°C

• Humidity: ≤90%
